APPLICATION
WQD series dirtywater pump is designed for dirty water,it can be widely used inindustry,mine,agriculture,environment protection, building construction, suchas drainage slurry,mortar,wastewater,and sewage containing flocks,paperscraps,mud and sand and other solid particles.It is also an ideal equipment forirrigation.
OPERATING LIMITS
· Max.medium temperature+40°C
· Max.ambient temperature+40°C
· PH level from 4-10
· Maximum passage for suspended solids ∅35
· Voltage fluctuation range:0.9-1.1 times of the ratedvalue
· lmmersion depth from 0.5m-5m
MOTOR INFORMATION
· Two-pole induction motor
· Single phase/three phase,50/60Hz(on demand)
· Thermal protector for single phase
· Insulation class:B
· Protection class:IPX8
MATERIAL
· Pump body:Casiron
· Motor housing:Cast iron
· Impeller:Cast iron
· Motor wire:copper
· Mechanical seal:Graphite&Ceramic
· Shaft:45#steel/stainless steel
